MikroTik Router RB4011iGS+RM

RB4011iGS+RM AL21400 1G/S+ all port test
Mode Configuration 1518 byte 512 byte 64 byte
kpps Mbps kpps Mbps kpps Mbps
Bridging none (fast path) 806,4 9,792.9 2312,9 9,473.6 5509,7 2,821.0
Bridging 25 bridge filter rules 806,4 9,792.9 1037,4 4,249.2 1153,2 590.4
Routing none (fast path) 806,4 9,792.9 1923,3 7,877.8 5092,3 2,607.3
Routing 25 simple queues 806,4 9,792.9 1046,6 4,286.9 960,3 491.7
Routing 25 ip filter rules 593,7 7,209.9 625,2 2,560.8 564,6 289.1
All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
IPsec test results
RB4011iGS+RM AL21400 IPsec throughput
Mode Configuration 1400 byte 512 byte 64 byte
kpps Mbps kpps Mbps kpps Mbps
Single tunnel AES-128-CBC + SHA1 92.1 1031.5 93.1 381.3 92.3 47.3
256 tunnels AES-128-CBC + SHA1 115.5 1293.6 117.4 480.9 132.3 67.7
256 tunnels AES-128-CBC + SHA256 115.5 1293.6 117.4 480.9 132.3 67.7
256 tunnels AES-256-CBC + SHA1 114.6 1283.5 111.4 456.3 126.3 64.7
256 tunnels AES-256-CBC + SHA256 114.6 1283.5 111.4 456.3 126.3 64.7
