The MikroTik RB941-2nD hAP Lite is a compact and affordable 2.4GHz wireless router and access point designed for homes, small offices, shops, apartments, network labs and other small-scale networking environments. It combines wireless connectivity, four Ethernet ports and MikroTik’s powerful RouterOS operating system in a small desktop enclosure.

The hAP Lite supports 802.11b/g/n wireless standards on the 2.4GHz band, with wireless data rates of up to 300Mbps. Its integrated wireless capability makes it suitable for providing Wi-Fi coverage while the four Ethernet ports allow wired devices such as computers, switches, printers and other network equipment to connect directly.

Powered by a 650MHz single-core Qualcomm Atheros processor and equipped with 32MB RAM, the RB941-2nD runs RouterOS with a Level 4 license. RouterOS provides considerably more networking functionality than a basic consumer wireless router, including routing, firewall, NAT, DHCP, bandwidth management, VLAN configuration and VPN functionality.

The device features four 10/100Mbps Ethernet ports. One Ethernet port is commonly used for the WAN connection, while the remaining ports can be configured for LAN connectivity. Because the Ethernet interfaces are Fast Ethernet rather than Gigabit Ethernet, wired connections are limited to 100Mbps.

Its compact design makes the hAP Lite easy to install on a desk, shelf or other suitable indoor location. It is also passively cooled, so there is no cooling fan producing mechanical noise.

The RB941-2nD is particularly useful where an inexpensive MikroTik device is needed for basic routing, wireless access, network experimentation or small deployments without requiring Gigabit Ethernet or 5GHz Wi-Fi.

Key Features

• 2.4GHz 802.11b/g/n Wi-Fi
• Up to 300Mbps wireless data rate
• 4 × 10/100Mbps Ethernet ports
• Qualcomm Atheros 650MHz CPU
• 32MB RAM
• 16MB storage
• RouterOS
• Level 4 RouterOS license
• Dual-chain 2.4GHz wireless
• Built-in internal antennas
• Compact desktop design
• Passive cooling
• Router and access-point functionality
• Firewall and NAT support
• DHCP server/client support
• Bandwidth management
• VPN support
• VLAN support
• Multiple configuration and management options
• Low-power operation
• Suitable for indoor use

Technical Specifications

Wireless Connectivity

The hAP Lite provides 2.4GHz 802.11b/g/n wireless connectivity.

It uses two internal wireless chains, allowing it to support wireless rates of up to 300Mbps under suitable 802.11n conditions.

The 2.4GHz band provides better range and wall penetration than higher-frequency Wi-Fi in many indoor environments, making it useful for basic home and small-office coverage.

Actual wireless performance depends on factors such as:

• Distance from the device
• Walls and building materials
• Wireless interference
• Number of connected devices
• Client-device capabilities
• Channel configuration
• Network traffic

The 300Mbps figure is a theoretical wireless link rate and should not be treated as guaranteed internet throughput.

Four Ethernet Ports

The RB941-2nD includes four 10/100Mbps Ethernet ports.

These ports can be configured through RouterOS for different networking roles.

Typical deployment can use:

• Ether1: WAN/Internet connection
• Ether2–Ether4: LAN devices

However, RouterOS allows the ports to be configured according to the requirements of the network.

Important

The Ethernet ports are 10/100Mbps Fast Ethernet, not Gigabit Ethernet.

This makes the hAP Lite better suited to basic networking environments where Gigabit wired connectivity is not required.

RouterOS

One of the main advantages of the hAP Lite over many basic wireless routers is MikroTik RouterOS.

RouterOS provides extensive configuration capabilities, including:

• Routing
• NAT
• Firewall
• DHCP
• DNS
• VLANs
• VPNs
• Bandwidth management
• Traffic monitoring
• Access control
• Wireless configuration
• IP addressing
• Static routes
• Network diagnostics
• User management

This makes the RB941-2nD useful not only as a home router but also as an affordable device for learning MikroTik networking.

RouterOS Level 4 License

The hAP Lite comes with a RouterOS Level 4 license.

This provides access to the RouterOS feature set required for normal router and wireless-access-point deployments.

It is also useful for students, technicians and network administrators who want to practice configuring MikroTik equipment in a real networking environment.

Access Point Functionality

The RB941-2nD can be configured as a wireless access point.

In this setup, the device can receive network connectivity through Ethernet and provide wireless access to compatible devices.

This makes it suitable for:

• Small offices
• Homes
• Shops
• Guest Wi-Fi
• Wireless network extensions
• Network labs

RouterOS provides extensive control over wireless settings, allowing administrators to configure SSIDs, security, channels and other network parameters.

Firewall and Network Security

RouterOS includes a configurable firewall that can be used to control traffic between network interfaces and protect connected devices.

Administrators can configure rules based on factors such as:

• Source address
• Destination address
• Protocol
• Port
• Interface
• Connection state

The hAP Lite can therefore perform basic firewall and NAT functions without requiring a separate firewall appliance.

Bandwidth Management

RouterOS supports traffic and bandwidth management features.

The hAP Lite can be configured to control bandwidth usage for different devices, IP addresses or network services.

This can be useful in environments where multiple users share a relatively limited internet connection.

Compact Design

The RB941-2nD has a compact enclosure measuring approximately 113 × 89 × 28mm.

Its small footprint allows it to be placed easily on:

• Desks
• Shelves
• Counters
• Small network spaces

The device uses passive cooling, helping it operate without the noise associated with a cooling fan.

Power

The hAP Lite operates using a 5V DC power supply.

Its maximum power consumption is approximately 3.5W, making it a relatively low-power networking device.

Why Choose the MikroTik RB941-2nD hAP Lite?

Affordable MikroTik Networking

Provides access to MikroTik’s RouterOS feature set at a lower entry point.

2.4GHz Wi-Fi

Offers 802.11b/g/n wireless connectivity with up to 300Mbps theoretical wireless rate.

Four Ethernet Ports

Provides four wired interfaces for flexible network configuration.

Advanced RouterOS

Supports routing, firewall, NAT, DHCP, VLANs, VPNs and bandwidth management.

Compact Design

Its small enclosure is easy to deploy in homes, shops and offices.

Low Power Consumption

Uses only a small amount of power compared with larger networking equipment.

Great for Learning

The hAP Lite is useful for students and networking enthusiasts learning MikroTik RouterOS and network configuration.

Ideal Applications

The MikroTik RB941-2nD hAP Lite is suitable for:

• Homes
• Apartments
• Small offices
• Shops
• Small businesses
• Guest Wi-Fi networks
• Basic wireless networks
• Small network deployments
• Network laboratories
• Networking training
• MikroTik learning environments
• RouterOS practice
• Basic internet-sharing applications

Benefits

• Affordable MikroTik networking solution
• 2.4GHz Wi-Fi connectivity
• Up to 300Mbps wireless rate
• Four Ethernet ports
• Powerful RouterOS features
• Level 4 license
• Firewall support
• NAT support
• DHCP support
• VPN capabilities
• VLAN support
• Bandwidth management
• Compact design
• Passive cooling
• Low power consumption
• Suitable for networking education and experimentation

What’s in the Box?

The standard package typically includes:

• MikroTik RB941-2nD hAP Lite
• 5V power adapter
• Product documentation

Package contents can vary depending on the distributor and market version.

Frequently Asked Questions

1. What is the MikroTik RB941-2nD?

The RB941-2nD hAP Lite is a compact 2.4GHz wireless router and access point with four Fast Ethernet ports and MikroTik RouterOS.

2. What Wi-Fi standard does it support?

It supports 802.11b/g/n on the 2.4GHz band.

3. What is the maximum Wi-Fi speed?

The maximum theoretical wireless rate is 300Mbps using compatible 802.11n configurations.

4. Does the hAP Lite support 5GHz?

No. The RB941-2nD is a 2.4GHz-only wireless device.

5. How many Ethernet ports does it have?

It has four 10/100Mbps Ethernet ports.

6. Are the Ethernet ports Gigabit?

No. They are Fast Ethernet ports supporting up to 100Mbps.

7. Does it have RouterOS?

Yes. The hAP Lite runs MikroTik RouterOS and comes with a Level 4 license.

8. Can it be used as an access point?

Yes. It can be configured as a wireless access point through RouterOS.

9. Does it support VLANs?

Yes. VLAN configuration is supported through RouterOS.

10. Does it support VPNs?

Yes. RouterOS provides VPN functionality, subject to the capabilities and resource limitations of this hardware.

11. Does it have a USB port?

No. The RB941-2nD does not include a USB port.

12. Does it support PoE?

The RB941-2nD does not provide the PoE-in/PoE-out functionality found on some other MikroTik models.

13. Does it have external antennas?

No. It uses built-in internal antennas.

14. Is the hAP Lite suitable for a large business?

It is primarily intended for smaller deployments. Larger networks may require more powerful MikroTik hardware, additional access points or dedicated switching equipment.

15. Can I use it for learning MikroTik?

Yes. Its RouterOS platform makes it useful for learning routing, firewalling, VLANs, wireless configuration and other networking concepts.

16. Can it manage internet bandwidth?

Yes. RouterOS provides bandwidth-management and queue features that can be configured according to the network requirements.

17. Is the hAP Lite suitable for basic home internet?

Yes. It can provide basic routing and 2.4GHz wireless connectivity for homes and small spaces.
