The MikroTik RB951-2n is a compact 2.4GHz wireless router and access point designed for basic home, small-office and networking applications. It combines wireless connectivity with five independent 10/100 Ethernet ports, making it suitable for connecting computers, switches, printers, IP devices and other network equipment.

The RB951-2n supports 802.11b/g/n Wi-Fi with a maximum wireless data rate of 150Mbps. Its integrated 2.4GHz radio uses 1×1 MIMO and onboard antennas, providing a simple all-in-one wireless networking solution.

At its core is an Atheros AR9331 processor with 32MB RAM, while MikroTik RouterOS Level 4 provides advanced networking capabilities such as routing, firewall configuration, NAT, DHCP, bandwidth management and wireless configuration.

The device supports passive PoE input through Ethernet port 1, as well as DC power through its power jack. Its compact 113 × 89 × 28 mm design also allows convenient placement on a desk or wall.

Important: The RB951-2n is an older/discontinued MikroTik model. Do not confuse it with the RB951Ui-2HnD, which has a faster CPU, more RAM, USB and PoE-out functionality.

Key Features

• 2.4GHz 802.11b/g/n wireless
• Up to 150Mbps wireless data rate
• 5 × 10/100 Fast Ethernet ports
• Atheros AR9331 processor
• 32MB onboard RAM
• 64MB NAND storage
• MikroTik RouterOS Level 4
• 1×1 MIMO wireless
• Built-in 2.4GHz antennas
• Up to 1.5dBi antenna gain
• Passive PoE input on Ethernet port 1
• 8–30V DC power input
• Compact and lightweight design
• Suitable for home and small-office networking

Technical Specifications

Wireless Connectivity

The RB951-2n provides 2.4GHz 802.11b/g/n wireless connectivity with a maximum data rate of 150Mbps.

Its integrated antenna system makes it suitable for basic wireless coverage without requiring an external antenna. The device uses 1×1 MIMO and has onboard PIF antennas with up to 1.5dBi gain.

It can be configured as a wireless access point or used in different RouterOS wireless networking configurations depending on the network requirements.

Ethernet Connectivity

The RB951-2n includes five independent 10/100 Ethernet ports.

This allows the router to connect multiple wired devices while simultaneously providing wireless connectivity. Ethernet ports support automatic straight-through/crossover cable correction, simplifying installation.

MikroTik RouterOS

One of the main advantages of the MikroTik RB951-2n is RouterOS.

RouterOS provides extensive networking functionality, including:

• IP routing
• Firewall
• NAT
• DHCP server and client
• DNS services
• Wireless management
• Bridge configuration
• VLAN configuration
• Bandwidth management
• Traffic control
• VPN functionality
• User management
• Network monitoring

This makes the RB951-2n considerably more configurable than a basic consumer wireless router.

Power & PoE

The RB951-2n can be powered through its DC power jack or through passive PoE on Ethernet port 1.

It accepts 8–30V DC input and consumes up to approximately 3W under maximum load. It is important to distinguish its passive PoE input from 802.3af/at active PoE.

Compact Design

Measuring only 113 × 89 × 28mm, the RB951-2n is designed for installations where space is limited.

Its housing includes mounting provisions, allowing it to be positioned conveniently in home or small-office environments.

Why Choose the MikroTik RB951-2n?

• Compact networking solution for smaller installations.
• Five Ethernet ports provide useful wired connectivity.
• 2.4GHz Wi-Fi supports everyday wireless networking.
• RouterOS Level 4 provides extensive configuration options.
• Passive PoE input offers flexible installation.
• Low power consumption helps keep operating costs down.
• Wall-mountable design makes installation convenient.
• Suitable for users who need more control than a basic plug-and-play router.

Ideal Applications

The MikroTik RB951-2n can be used for:

• Home networks
• Small offices
• Basic wireless access
• Small wired networks
• Guest Wi-Fi
• Network labs and learning
• RouterOS training
• Internet sharing
• Basic network routing
• Small branch installations
• Secondary access-point deployments

Benefits

Reliable Wired Connectivity

Five Fast Ethernet ports allow several wired devices to connect directly.

Flexible Wireless Networking

The integrated 2.4GHz radio provides convenient Wi-Fi connectivity.

Advanced Configuration

RouterOS gives administrators extensive control over routing, firewall, wireless and network-management functions.

Low Power Consumption

With consumption of up to approximately 3W, the device is designed for efficient operation.

Easy Installation

Its small enclosure and wall-mounting provisions make it easy to position in suitable locations.

What’s in the Box?

• MikroTik RB951-2n RouterBOARD
• Plastic enclosure
• Power adapter

Frequently Asked Questions

Is the MikroTik RB951-2n a router or access point?

It can function as both a wireless router and access point, depending on how RouterOS is configured.

Does the RB951-2n support 5GHz Wi-Fi?

No. The RB951-2n operates on the 2.4GHz band.

How many Ethernet ports does it have?

It has five 10/100Mbps Ethernet ports.

What Wi-Fi standard does it support?

It supports 802.11b/g/n, with a maximum wireless data rate of 150Mbps.

Does it support PoE?

Yes. Ethernet port 1 supports passive PoE input from 8–30V DC. It does not use standard 802.3af active PoE.

Does it have USB?

The RB951-2n does not have USB. The RB951Ui-2HnD is a different model that includes USB.

Is the RB951-2n suitable for a small office?

Yes, particularly for basic wired and 2.4GHz wireless networking where Gigabit Ethernet and newer Wi-Fi standards are not required.

Is the RB951-2n still manufactured?

MikroTik lists the RB951-2n as discontinued.
